Powerful 190A Charging Current: Handles heavy energy demands effortlessly with a maximum charging and discharging current of 190A for 48V systems.
Rugged IP66 Design with Touch Display: Enjoy easy operation via the colorful touch LCD, fully protected against dust and heavy rain by an IP66 enclosure.
Retrofit Capabilities: AC coupling technology enables quick and easy integration into homes that already have solar panels installed.
Diesel Generator Storage: Effectively stores power generated from diesel generators into batteries, ensuring zero energy waste.
Time-of-Use Rate Management: Program up to 6 charging/discharging schedules to perfectly align with your local utility's pricing structure.
High Scalability: Parallel up to 16 inverters to create a micro-grid level system for both on-grid and off-grid demands.
Model | LD06H-SM-8K-EP-D |
Battery Input Data | |
Battery Type | Lead-acid or Lithium-ion |
Battery Voltage Range(V) | 40-60 |
Max. Charging Current(A) | 190 |
Max. Discharging Current(A) | 190 |
Charging Strategy for Li-Ion Battery | Self-adaption to BMS |
Number of Battery Input | 1 |
PV String Input Data | |
Max. PV Input Power(W) | 12000 |
Max. PV Input Voltage(V) | 500 |
Start-up Voltage(V) | 125 |
PV Input Voltage Range(V) | 125-500 |
MPPT Voltage Range(V) | 150~425 |
Full Load MPPT Voltage Range(V) | 200~425 |
Rated PV Input Voltage(V) | 370 |
Max. Operating PV Input Current(A) | 26+26 |
Max. Input Short-Circuit Current(A) | 34+34 |
No. of MPP Trackers/No. of Strings MPP Tracker | 2/2+2 |
Max. Inverter Backfeed Current to The Array | 0 |
AC Input Data | |
Rated AC Input Active Power(W) | 8000 |
Max. AC Input Active Power(W) | 8800 |
Peak Power(off grid)(W) | 2 times of rated power, 10s |
Rated AC Input/Output Current(A) | 36.4/34.8 |
Max. Rated AC Input/Output Current(A) | 40/38.3 |
Max. Continuous AC Passthrough(grid to load)(A) | 50 |
Max. Output Fault Current(A) | 80 |
Max. Output Overcurrent Protection(A) | 140 |
Rated Input Voltage/Range(V) | 220V/230V 0.85Un-1.1Un |
Grid Connection Form | L+N+PE |
Rated Input Grid Frequency/Range | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz |
Power Factor Adjustment Range | 0.8 leading-0.8 lagging |
Total Harmonic Distortion(THDi) | <3% (of nominal power) |
DC Injection Current | <0.5% ln |
Efficiency | |
Max. Efficiency | 97.60% |
Euro Efficiency | 96.50% |
MPPT Efficiency | >99% |
Equipment Protection | |
DC Polarity Reverse Connection Protection | Yes |
AC Output Overcurrent Protection | Yes |
AC Output Overvoltage Protection | Yes |
AC Output Short Circuit Protection | Yes |
Thermal Protection | Yes |
DC Terminal Insulation Impedance Monitoring | Yes |
DC Component Monitoring | Yes |
Ground Fault Current Monitoring | Yes |
Arc fault circuit interrupter(AFCI) | Optional |
Power Network Monitoring | Yes |
Island Protection Monitoring | Yes |
Earth Fault Detection | Yes |
DC Input Switch | Yes |
Overvoltage Load Drop Protection | Yes |
Residual Current (RCD) Detection | Yes |
Surge Protection Level | Type II(DC) / Type II(AC) |
Interface | |
Display | LCD+LED |
Communica ion Interface | RS232, RS485, CAN |
Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) |
General Data | |
Operating Temperature Range | -40 to +60℃, >45℃ Derating |
Permissible Ambient Humidity | 0-100% |
Permissible Al itude | 2000m |
Noise(dB) | <30 dB |
Ingress Protection(IP) Rating | IP 66 |
Inverter Topology | Non-Isolated |
Over Voltage Category | OVC II(DC), OVC III(AC) |
Weight(kg) | 27 |
Cabinet size(mm) (W×H×D） | 340×580×234 |
Warranty | 5 Years (10 Years Optional) |
Type of Cooling | Intelligent Air Cooling |
Grid Regulation | IEC 61727,IEC 62116,EN 50549 |
Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
