Ultra-High 250A Current: Offers a massive charging and discharging current of 250A, unlocking the full potential of your low-voltage 48V battery systems.
Durable IP66 & Touch LCD: Safely install outdoors or indoors with IP66 protection, while controlling the system effortlessly via the colorful touchscreen.
Advanced AC Coupling: Breathe new life into existing solar grid-tied systems by upgrading them to energy storage systems with minimal wiring changes.
Maximize Generator Efficiency: Support storing energy from diesel generators directly into your batteries to avoid running generators at low, inefficient loads.
Custom Charging Schedules: Program 6 specific time periods for battery operation, ensuring you buy cheap energy and use free solar when it matters.
Micro-Grid Ready: Parallel up to 16 inverters to satisfy extremely high single-phase load demands in both on-grid and off-grid scenarios.
Model | LD06H-SM-10K-EP-D | LD06H-SM-12K-EP-D |
Battery Input Data | ||
Battery Type | Lead-acid or Lithium-ion | |
Battery Voltage Range(V) | 40-60 | |
Max. Charging Current(A) | 220 | 250 |
Max. Discharging Current(A) | 220 | 250 |
Charging Strategy for Li-Ion Battery | Self-adaption to BMS | |
Number of Battery Input | 1 | |
PV String Input Data | ||
Max. PV access Power(W) | 20000 | 24000 |
Max. PV Input Power(W) | 15000 | 18000 |
Max. PV Input Voltage(V) | 500 | |
Start-up Voltage(V) | 125 | |
PV Input Voltage Range(V) | 125-500 | |
MPPT Voltage Range(V) | 150~425 | |
Full Load MPPT Voltage Range(V) | 200~425 | |
Rated PV Input Voltage(V) | 370 | |
Max. Operating PV Input Current(A) | 26+26+26 | |
Max. Input Short-Circuit Current(A) | 44+44+44 | |
No. of MPP Trackers/No. of Strings MPP Tracker | 3/2+2+2 | |
Max. Inverter Backfeed Current to The Array | 0 | |
AC Input Data | ||
Rated AC Input Active Power(W) | 10000 | 12000 |
Max. AC Input Active Power(W) | 11000 | 13200 |
Peak Power(off grid)(W) | 2 times of rated power, 10s | |
Rated AC Input/Output Current(A) | 45.5/43.5 | 54.6/52.2 |
Max. Rated AC Input/Output Current(A) | 50/47.9 | 60/57.4 |
Max. Continuous AC Passthrough(grid to load)(A) | 60 | 60 |
Max. Output Fault Current(A) | 100 | 120 |
Max. Output Overcurrent Protection(A) | 180 | |
Rated Input Voltage/Range(V) | 220V/230V 0.85Un-1.1Un | |
Grid Connection Form | L+N+PE | |
Rated Input Grid Frequency/Range | 50Hz/45Hz-55Hz 60Hz/55Hz-65Hz | |
Power Factor Adjustment Range | 0.8 leading-0.8 lagging | |
Total Harmonic Distortion(THDi) | <3% (of nominal power) | |
DC Injection Current | <0.5% ln | |
Efficiency | ||
Max. Efficiency | 97.60% | |
Euro Efficiency | 96.50% | |
MPPT Efficiency | >99% | |
Equipment Protection | ||
DC Polarity Reverse Connection Protection | Yes | |
AC Output Overcurrent Protection | Yes | |
AC Output Overvoltage Protection | Yes | |
AC Output Short Circuit Protection | Yes | |
Thermal Protection | Yes | |
DC Terminal Insulation Impedance Monitoring | Yes | |
DC Component Monitoring | Yes | |
Ground Fault Current Monitoring | Yes | |
Arc fault circuit interrupter(AFCI) | Optional | |
Power Network Monitoring | Yes | |
Island Protection Monitoring | Yes | |
Earth Fault Detection | Yes | |
DC Input Switch | Yes | |
Overvoltage Load Drop Protection | Yes | |
Residual Current (RCD) Detection | Yes | |
Surge Protection Level | Type II(DC) / Type II(AC) | |
Interface | ||
Display | LCD+LED | |
Communication Interface | RS232, RS485, CAN | |
Monitor Mode | GPRS/WIFI/Bluetooth/4G/LAN(optional) | |
General Data | ||
Operating Temperature Range | -40 to +60℃, >45℃ Derating | |
Permissible Ambient Humidity | 0-100% | |
Permissible Altitude | 2000m | |
Noise(dB) | <45 dB | |
Ingress Protection(IP) Rating | IP 66 | |
Inverter Topology | Non-Isolated | |
Over Voltage Category | OVC II(DC), OVC III(AC) | |
Weight(kg) | 35 | |
Cabinet size(mm)（W×H×D） | 413×640×257.5 (Excluding connectors and brackets) | |
Warranty | 5 Years (10 Years Optional) | |
Type of Cooling | Intelligent Air Cooling | |
Grid Regulation | IEC 61727,IEC 62116,EN 50549 | |
Safety EMC/Standard | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 | |
